Cutting thickness | 10-100mm |
Cutting width | 60-200mm |
Cutting length | 2000mm/4000mm/6000mm |
Max. section area | 100*200mm |
Feeding speed | 5-30m/min |
Saw size | Φ450mm*30mm |
Saw shaft size | Φ30mm |
Saw spindle speed | 3500rpm |
Feed servo motor | 750w |
Saw motor | 7.5kw |
Pressure | 5-6kg/cm2 |
Dust exit | Φ100*2 |
Overall size (Depends on 4meter one) | 7200*1200*1700mm |
Packing size: Main body Feeding table Rail | 1500*1100*1700mm 2500*700*450mm 5600*250*250mm |
Weight | 1100kgs |
